Description
Details:
Specifications:
Application For
- Intel TDP 150W
- LGA2011-v3/LGA2011/LGA1366/LGA115X
- High End Desktop i7
- Core i7/i5/i3
- Pentium G
- Celeron G
- AMD TDP 140W
- AM4/AM3+/AM3/AM2+/AM2/FM2+/FM2/FM1 (NOTE: Manuals for AM4, please refer to FM2+/FM2/FM1/AM3+/AM3/AM2+/AM2)
- Ryzen
- APU A12/A10/A8/A6/A4
- FX 8/6/4-Core
- Phenom II X6/X4/X3/X2
- Athlon II X4/X3/X2
- Athlon X4
Technical Spec
- Overall Dimension: 135X84.8X156 mm
- Fan Dimension: 120X120X25 mm
- Net Weight: 870 g
- Bearing Type: Hydro Bearing
- Rated Voltage: 12VDC
- Operating Voltage: 10.8~13.2VDC
- Started Voltage: 7VDC
- Rated Current: 0.23A(MAX)
- Power Input 2.76W
- Fan Speed: 500±150~1500±10%RPM
- Max. Air Flow: 70.08CFM
- Noise: 17.8~29.5dB(A)
